FEATURES
  • The hydraulic system has a dual-pump confluence with steering always in priority, reducing energy loss.
  • 309° panoramic visibility gives the operator a very comfortable work environment in the cab.
  • Fully-sealing and micro-pressuring system ensures the cab is clean and quiet.
  • Single layer radiator and big range fin spacing for high efficiency and easy maintenance.
SPECIFICATIONS
Base
Operating Weight 4,000 kg
Bucket Capacity 2.3 m³
Rated Power 129 kW (173 hp / 175 ps) @ 2,000 rpm
Performance
Total Cycle Time 9.58 s
Tipping Load-full Turn 8,500 kg
Bucket Breakout Force 124 kN
Dump Clearance, Full Height Discharge 2,880 mm
Dump Reach, Full Height Discharge 1,108 mm
Engine
Model Weichai WP6G175E201
Emissions Tire 2 / Stage II
Dimensions
Length with Bucket Down 7,572 mm
Width over Tires 2,480 mm
Cab Height 3,300 mm
