FEATURES
  • 1. Improved Efficiency

  • We use an innovative electric-hydraulic control system with large displacement pump and proportional control valve. Electric-hydraulic control minimizes energy waste, reduces hydraulic fluid leaks, and enhances overall efficiency.

  • 2. Toughness & Durability

  • Heavy-duty chassis and working units matched to the toughest working conditions and tested to the extreme.

  • 3. Enhanced Productivity

  • Intelligent remote diagnostics simplifies maintenance procedures, reduces costs, and maximizes uptime and productivity. This smart feature enables efficient monitoring and maintenance, software updates and diagnostic checks and calibrations to be performed remotely, minimizing downtime and optimizing performance. Other intelligent features include, Auto ThermoStat which adjusts the heating, ventilation, and air conditioning (HVAC) settings to match the operating conditions.

SPECIFICATIONS
Base
Operating Weight 122,000 kg
Rated Power 567 kW (760 hp / 771 ps) @ 1,800 rpm
Bucket Capacity 8.0 m3
Performance
Arm Digging Force 491 kN
Bucket Digging Force 610 kN
Working Range
Max. Digging Reach 13,997 mm
Max. Digging Depth 8,112 mm
Max. Cutting Height 12,595 mm
Min. Front Swing Radius 6,489 mm
Engine
Model Cummins QSK23
Emission Tier3 / Stage IIIA
Hydraulic System
Main Pumps Total Flow 2,040 L/min
Relief Pressure, main 37 MPa
