FEATURES
  • Unmatched performance driven by the Cummins Engine enhances torque output with more power and breakout force at lower engine speeds.
  • Options for auxiliary hydraulic piping include bidirectional variable high flow line, an additional line for rotating attachments and also a single acting line. The quick coupler further ensures you get the most out of your machine by easily switching between a wide range of attachments to suit any application.
  • Ergonomically designed cab for LiuGong E series excavator, with great visibility, expansive room, new multi-function LCD monitor, automatic air conditioner, large storage space, provide most comfortable working environment.
  • Hydraulic request signals detect activity, decreasing and increasing engine speed as required. Power is supplied only as needed, achieving optimum fuel efficiency.
  • Outstanding stability and durability come from an X-type reinforced frame and the long track beam and crawler system.
SPECIFICATIONS
Base
Operating Weight 57,300 kg
Rated Power 280 kW (375 hp / 381 ps) @ 2,000 rpm
Net Power 260 kW (349 hp / 354 ps) @ 2,000 rpm
Bucket Capacity 0.73 m³
Performance
Arm Digging Force 268 kN
Bucket Digging Force 290 kN
Transport Dimension
Shipping Length 18,000 mm
Shipping Width 3,540 mm
Shipping Height 3,625 mm
Track Gauge 2,740 mm
Engine
Model Cummins QSM11
Emission Tier 3 / Stage IIIA
Hydraulic System
Main Pumps Total Flow 2x380 L/min
Relief Pressure, main 34.3 MPa
