FEATURES

1. Improved Efficiency

We use an innovative electric-hydraulic control system with large displacement pump and proportional control valve. Electric-hydraulic control minimizes energy waste, reduces hydraulic fluid leaks, and enhances overall efficiency.

2. Toughness & Durability

Heavy-duty chassis and working units matched to the toughest working conditions and tested to the extreme.

3. Enhanced Productivity

Intelligent remote diagnostics simplifies maintenance procedures, reduces costs, and maximizes uptime and productivity. This smart feature enables efficient monitoring and maintenance, software updates and diagnostic checks and calibrations to be performed remotely, minimizing downtime and optimizing performance. Other intelligent features include, Auto ThermoStat which adjusts the heating, ventilation, and air conditioning (HVAC) settings to match the operating conditions.

SPECIFICATIONS
Base
Operating Weight 75,000 kg
Rated Power 563 kW (755 hp / 766 ps) @ 2,100 rpm
Bucket Capacity 5.0 m3
Performance
Arm Digging Force 350 kN
Bucket Digging Force 384 kN
Transport Dimension
Shipping Length 13,086 mm
Shipping Width 4,252 mm
Shipping Height 4,961 mm
Track Gauge 3,350 mm
Engine
Model Cummins QSM15
Emission Tier3 / Stage IIIA
Hydraulic System
Main Pumps Total Flow 2x504 L/min
Relief Pressure, main 34.3 MPa
