Model
Main parameter
Upper chassis
Ratractable undercarriage
| Wall width | 0.6-1.2 m |
| Wall depth | 75(Standard 60) m |
| Max. lifting force | 550 kN |
| Base machine weight (without frame or shovel) | 75 t |
| Total height | 17,340 mm |
| Max distance from shovel to ground | 5,500 mm |
| Engine | ChineseⅢ |
| Max speed | 1,900 rpm |
| Rated Output power | 272 kW |
| Crawler length | 5,600 mm |
| Track shoe width | 800 mm |
| Traction force | 600 kN |
| Traveling speed | 1.7 km/h |
